Specification Table
| Mobile Computing Platform | Intel® Core™ i5-114567 Processor/Intel Core i7-118567 Processor 8 MB cache, up to 4.4GHz with Intel Turbo Turbo Boost Technology/12 MB cache, up to 4.8 GHz with Intel Turbo Turbo Boost Technology |
|---|---|
| Operating System | Windows 10 Pro |
| Memory Storage | 8GB RAM (6468 Max.) 256GB/51268/1TB SSD option |
| Display | Full-HD:
14" Active Matrix (TFT) colour LCD 1366 x 768 pixels Full-HD Touch: 14''Active Matrix(TFT) colour LCD 1920 x 1080 pixels/with, 1000 cd/m2(nt) Capacitive 10 finger Touch Screen/Touch (Glovel and Pen mode with 1,000 cd/m2(nt) Graphic Chip: Intel UHD Graphics 620 optional: AMD Radeon Pro WX in TOUGHBOOK Universal Bay |
| Front Camera | 2 MP with IR/privacy shutter (Windows Hello compliant) |
| Sound | WAVE and MIDI playback, Intel High Definition Audio subsystem support |
| Enhanced Voice Recognition | 4 Microphones (included in Front Camera) |
| LAN | IEEE 802.3 10Base-T/IEEE 802.3u 100BASE-TX / IEEE 802.3ab 1000BASE-T (2nd GLAN optional) |
| Bluetooth | 5.1 |
| Wireless Lan | Intel Dual Band Wireless-AC 9560 |
| Mobile Broadband* | 4G LTE |
| GPS | u-blox NEO-M8N (supports GPS, GLONASS, Beidou, Galles, GAGAN) |
| Interface | USB 3.2/3.1 :x2 Thunderbolt 4:x1 Micro SDXC Memory Card :x1 HOMI:x1 Headset :x1 DC In :x1 Port Replicator: x1 Dual Path Through Connector :x1 nano SIM slot : x1 |
| TOUCHBOOK Universal Bay optional | Select One: Discrete GPU Smart Card Reader DVD Multi Drive Blu Ray Drive 2nd 550 |
| Front Expansion Slot Optional | Select one: 2nd Battery Finger Print Reader Contactless Smart Card Reader (HF-RFID) Smart Card Reader |
| Rear Expansion Slot Optional | Select one:VGA + True Serial 4th USB 3.2/3.1 VGA + True SeriaL + 2nd GLAN VGA + True Serial + Rugged USB 2.0 |
| Power | AC Adaptor: Input: 100V-240V AC, 50Hz/60Hz, Dutput: 15,6V DC, 7.05A Battery: Lithium-Ion 10.8V, 6500mAh (typ.), 630mAh [min.] Battery Life HD: Approx. 20 hours (Mobile Mark 2014) Approx 40 hours with 2nd battery (Mobile Mark 20141 Battery Life Full HD/Touch Screen: Approx. 19 hours (Mobile Mark 2014) Approx 38 hours with 2nd battery (Mabille Mark 2014) |
| Dimensions (WxHxD) | 345mm x 272mm x32.8mm |
| Weight | HD:Approx. 2.80kg Full HD:Approx.2.13kg Full HD Touch:Approx.2.22kg |
| Ruggedisation | Dust & Water Resistance test: IP53 Gravity drop resistance test: 91cm Operating temprature:-29*c to +60*c Storage temprature:-51*c to +71*c |
| Backlit Keyboard | Optional |
