| CPU | Intel® Core™ i5-1145G7 vPro® processor Up to 4.4GHz with Turbo Boost, 8MB cache.
Intel® Core™ i7-1185G7 vPro® processor Up to 4.8GHz with Turbo Boost, 12MB cache. |
|---|---|
| Operating System | Windows 10 or 11 Pro 64-bit Enterprise ready driver packages including CAB files and one-click driver bundles |
| Memory Storage | User-upgradeable RAM (up to 2 DIMM's) 16-64GB total (DDR4-3200MHz)4,5 Main SSD: 512GB, 1TB or 2TB quick-release OPAL NVMe with heater; opt. FIPS 140-2 encrypted4 Optional 2nd SSD: 512GB or 1TB quick-release OPAL SATA with heater4 |
| Display |
14.0" FHD 1920 x 1080 capacitive gloved touch 1-1200 nit
IPS with direct bonding Anti-reflective (AR) screen treatment |
| Graphics |
Intel® UHD Graphics (units with 1 DIMM) Intel® Iris® Xe Graphics (units with 2 DIMM)5 AMD Dedicated Graphics1 Supports up to 4 displays Concealed Mode; Day/Night Mode |
| Audio | Integrated tetra-array microphone Intel® High Definition Audio compliant Integrated 95db speakers (top-facing) keyboard volume and mute controls |
| Webcam | 5MP w/privacy cover & tetra-array mic Infrared with Windows Hello support |
| Keyboard and Input | Stylus pen, stylus holder and cleaning cloth 6 modes (auto, rain, glove, touch, pen, pen/touch) User-removable 82-key keyboard3 – 8 programmable buttons/keys (P1-P4, A1-A4) – Color-selectable backlit with 4 adjustable levels (emissive or rubber) Gen2 resistive touchpad with multi touch |
| Interface |
USB-C Thunderbolt™ 4, 40Gbps 3A (w/PD). USB-A x2 (10Gbps 0.9A, 5Gbps 0.9A). Optional USB-A x2 5Gbps8. MicroSDXC UHS-I. HDMI 4K (optional 2nd HDMI 4K)8 Optional VGA8 Ethernet 1Gbps RJ-45 Optional 2nd Ethernet 1Gbps RJ-458 Optional Serial (True) D-sub 9-pin8 Audio In/Out 3.5mm Dual SIM (Nano-SIM 4FF x1, eSIM x1) |
| Wireless |
Optional 4G EM7690 (up to 2Gbps) – 4G (LTE, LTE-A) – Multi carrier (AT&T, First Net, Verizon) – Satellite GPS & CBRS Band 48 Capable9 Optional 5G EM9190 (up to 5.5Gbps)1 – 4G (LTE, LTE-A), 5G (Sub6, C-band, mmWave) – Multi carrier (AT&T, First Net, Verizon) – Satellite GPS & CBRS Band 48 Capable9 Optional dedicated GPS (u-blox NEO-M8J) Opt. quad antenna pass-through (BIOS selectable) Intel® Wi-Fi 6 AX201 (up to 2.4Gbps) Bluetooth® v5.1 (Class 1) Airplane mode Fn key |
| Power | Li-Ion battery: – 18 hours (36 hours w/opt. 2nd battery) 10, 11 – 10.8V, 6500mAh Hot swap with optional 2nd battery11 Battery charging time: 3 hours (each battery)10 TOUGHBOOK Smart Battery Technology AC Adapter: AC 100V-240V worldwide power, auto sensing/switching |
| Security Feature | Intel® Hardware Shield Secured-core PC TPM v.2.0 NIST BIOS compliant Persistence® technology by Absolute in BIOS12 Secure Wipe Kensington cable lock slot Encrypted SSD's (OPAL & opt. FIPS 140-2) Optional locking screws for SSD and xPAK's Optional fingerprint reader xPAK's6 – Secured-core PC (363 DPI) – Active Directory (385 DPI) Optional insertable Smart Card reader xPAK's7,11 Optional contactless Smart Card reader xPAK6 – 13.56MHz (ISO 14443 A/B, ISO 18092) |
| Power | AC Adaptor: Input: 100V-240V AC, 50Hz/60Hz, Dutput: 15,6V DC, 7.05A Battery: Lithium-Ion 10.8V, 6500mAh (typ.), 630mAh [min.] Battery Life HD: Approx. 20 hours (Mobile Mark 2014) Approx 40 hours with 2nd battery (Mobile Mark 20141 Battery Life Full HD/Touch Screen: Approx. 19 hours (Mobile Mark 2014) Approx 38 hours with 2nd battery (Mabille Mark 2014) |
| Dimensions & Weight | 11.9"(L) x 13.9"(W) x 2.1"(H) 7.4 lbs. |
| Integrated Options | 5G EM91901 or 4G EM7690 modem Dedicated GPS (u-blox NEO-M8J) Quad antenna pass-through Main SSD: OPAL / FIPS 140-2 Encrypted – 512GB.......FZ-VSD400T1U / FZ-VSF400T1M – 1TB........FZ-VSD401T1U / FZ-VSF401T1M – 2TB.......FZ-VSD402T1U / FZ-VSF402T1M Memory Cards – 16GB DDR4.........FZ-BAZ2116 – 32GB DDR4.........FZ-BAZ2132 Keyboard – Backlit Emissive.......FZ-VKB55107U – Backlit Rubber.......FZ-VKB40207W Right Expansion Area – Insertable Smart Card xPAK.........FZ-VSC401U – 2nd Battery.......FZ-VZSU1XU Left Expansion Area xPAK's – Barcode Reader........FZ-VBR401M – Blu-ray Drive........FZ-VBD401U – DVD Drive........FZ-VDM401U – Insertable Smart Card.......FZ-VSC402U – 512GB 2nd SSD OPAL.......FZ-V2S400T1U – 1TB 2nd SSD OPAL......FZ-V2S401T1U Rear Expansion Area xPAK's – VGA + Serial (true) + LAN FZ-VCN401U – USB-A + HDMI + Serial (true) FZ-VCN402U – USB-A (x2) + HDMI FZ-VCN403U |
| Warranty | 3-year limited warranty, parts and labor |
