| Mobile Computing Platform |
|
|---|---|
| Operating System | Windows 10 Pro |
| Storage | 512GB OPAL NVMe SSD (1TB optional) |
| RAM | 16GB (max. 32GB) DDR4 |
| Graphic Chip | Intel® UHD Graphics |
| LCD | 12.0" Active Matrix (TFT) colour LCD 2160 x 1440 (QHD) LCD with sunlight-viewable glove-enabled capacitive touchscreen (up to 1.200cd/m²), IP55 Digitiser |
| Bluetooth™ | 5.1 + EDR Class 1 |
| GPS* | U-Blox NEO-M8N |
| Sound | WAVE and MIDI playback, Intel® High Definition Audio subsystem support |
| Camera | Front: 2 MP with IR / privacy shutter (Windows Hello compliant) Rear: 8mpixel with autofocus and LED flash |
| SD/SDXC Memory Card* | x1 (Keyboard) |
| Configuration port (Tablet)** | Serial, 2D Barcode Reader, 2nd USB 2. |
| Interface | USB 3.1: x3 (x1 Tablet, x2 Keyboard) USB 3.1 type C PD: x1 USB 2.0: x1 optional (Tablet)**x1 (Keyboard) HDMI: x1 (Tablet)x1 (Keyboard) VGA: x1 (Keyboard) LAN: x1 (Tablet) x1 (Keyboard) Native Serial Port: x1 optional (Tablet)**x1 (Keyboard) Headset: x1 (Tablet)x1 (Keyboard) DC In: x2 (Tablet + Keyboard) Port Replicator: x1 (Keyboard) Dual Antenna Connector: x1 (Keyboard) |
| Business Expansion Module*** | Smart Card Reader, Fingerprint Reader |
| Power | Power Management: ACPI BIOSM AC Adapter: Input: 100 V - 240 V AC, 50 Hz/ 60 Hz, Output: 15.6 V DC, 4.06A Battery: Standard: x2 Li-Ion (3 cell, 22Whr)Extended: x2 Li-Ion (6 cell, 45 Whr) optional Battery Life: Standard: Approx. 10 hours (Mobile Mark™ 2014)Extended: Approx. 20 hours (Mobile Mark™ 2014) |
| Operating Temperature | MIL-STD 810G, -29 °C to 60 °C *** |
| Security* | TPM (TCG V2.0 compliant) Password security (supervisor password, user password, hard disc lock) Integrated hardware security lock slot |
| Dimensions (W x H x D) | Standard Battery: 313.0 mm × 288.4 mm × 46.1 mm / 12.3" × 11.4" × 1.8" Extended Battery: 313.0 mm x 288.4 mm x 56.6 mm / 12.3" x 11.4" x 2.2" |
| Weight | Standard Battery: 2.78kg / 6.2lb |
| Standard Configuration | CF-33mk2, 16GB RAM, 512GB SSD, 2x standard battery pack, IP55 digitiser pen |
| Included in the box | Power Supply, Power Cord, Display cleaning cloth and User Manual |
| Accessories | AC Adapter CF-AA5713A7 Desktop port replicator CF-VEB331U7 Standard battery pack (3 cell) CF-VZSU1AW7 Extended battery pack (6 cell) CF-VZSU1BW7 Digitizer Stylus pen CF-VNP023U7 |
| Testing Standards | Water Resistance IEC529 (JIS C0920) IPx5*** Dust Resistance: IEC529 (JIS C0920) IP6x*** Drop Resistance: MIL-STD 810G, 150cm*** |
| Standard(s) for Safety: | UL 121201-Nonincendive Electrical Equipment for Use in Class I and II, Division 2 and Class III, Divisions 1 and 2 Hazardous (Classified) Locations, CSA C22.2 No. 213-17-Nonincendive Electrical Equipment for Use in Class I and II, Division 2 and Class III, Divisions 1 and 2 Hazardous (Classified) Locations |
